WAPA HIGH MAST / FLOOD LIGHTING

flood-lighting

  • Model Name WP050 WP075 WP100
    Power Consumption 50W 75W 100W
    Luminous Efficacy* 135 lm/w
    Luminous Flux* 6,750 lm 10,125 lm 13,500 lm
    Color Temperature 5000K (3500K, 4000K, 6500K available)
    Color Rendering 80 Ra
    Light Distribution Asymmetric Wide
    Input Voltage AC100 ~ 240V / AC100 ~ 277V
    Frequency 50 ~ 60 Hz
    Operation Temperature -22°F ~ 140°F / -30°C ~ 60°C
    Size (W x L x H) 15.4 x 10.3 x 4.0 (inch) / 390 x 262 x 94.3 (mm) 21.7 x 10.4 x 5.5 (inch) / 552 x 264 x 140 (mm)
    Weight (Driver Included) 7.1 lb / 3.2 Kg 9.3 lb / 4.2 Kg
    Body Cast Aluminum
    Optic Silver Coating Reflector
    Cover Tempered Glass 3.2T (Clear)
    Finish Coating Powder Coating
    IP Rating / IK Rating IP66 / IK07
    Mounting Option Wall Mount / Swivel Bracket / Pole Mount
    Control System Wireless/ Sensor (Daylight)
    Warranty 5 Years (12 hours usage per day)
    *Tolerance ±5%
