TANA EXPLOSION PROOF LIGHTING

explosion proof lighting

  • special explosion proof lighting specs

  • Model Name TAN060 TAN080 TAN100
    Power Consumption 60W 80W 100W
    Luminous Efficacy* 130 lm/w
    Luminous Flux* 7,800 lm 10,400 lm 13,000 lm
    Color Temperature 5000K (3000K / 5700K available)
    Color Rendering 80 Ra
    Size (D x H) Ø11.4 x 12.2 (inch) / Ø290.0 x 310.0 (mm)
    Input Voltage AC100 - 240V / AC100 - 277V
    Operating Temperature -22°F ∼ 104°F / -30°C ∼ 40°C
    Weight (Driver Included) 20.9 lb / 9.5kg
    Body Cast Aluminium
    Cover Tempered Glass 15.0T (Clear)
    Finish Coating Powder Coating
    IP Rating IP66
    Mounting Option Surface Mount
    Warranty 5 Years (12 hours usage per day)
    *Tolerance ±5%
  • explosion proof lighting

    explosion proof lighting

    explosion proof lighting



  • RECOMMENDED PLACES: OIL FACTORIES

    explosion proof lighting application

  • SPECIFICATIONSPRODUCT SPECIFICATIONSQUICKTIME VRQUICKTIME VRUPDATE / DRIVERIES FILESUSER GUIDEUSER GUIDE
