SUFA-M STADIUM LIGHTS

  • Model Name SFM1K2 SFM400 SFM400 (W/C)
    Power Consumption 1200W 400W 400W
    Luminous Efficacy* 100 / 105 / 110 lm/W 90 / 95 / 100 lm/W
    Luminous Flux* 120,000 / 126,000 / 132,000 lm 40,000 / 42,000 / 44,000 lm 36,000 / 38,000 / 40,000 lm
    Color Temperature 5000K (3000K, 4000K, 5700K available) 3,000 / 4,000 / 5,000 / 6,000K available
    Color Rendering 70 / 80 / 90 Ra 80 / 90 Ra
    Light Distribution 15 / 30 / 45°
    Input Voltage 200 ~ 277 / 347 ~ 480 V
    Operation Temperature -30℃ ~ 55℃
    Weight 21 kg / 46.3 lb 8 kg / 17.6 lb
    Body Cast Aluminum
    Finish Powder Coating
    Cover Tempered Glass 3.2T (Clear), Anti UV & Dust, Shatter Proof
    IP IP66
    Control System Wired (RS-485)
    *Tolerance: ± 5%
